TV Wall Bracket |
Click the catalogue at the top, or scan the QR code to view more product information... |
|
-
 Model : A-2660C |
26''- 55'' max load capacity:34.1kgs(75Ibs) |
|
|
Ceiling mount Flat panel Tilt mount For screen sizes 26''- 55''
> Fits most 26''- 55'' flat panel TV
> VESA compliance: 100*100,200*100,200*200,
200*300,300*300,200*400.300*400,400*400
> Load capacity: 75Ibs(34.1kg)
> Tilt angle: +15°/-5°
> Material: SPCC with coating finished |
|
-
| Model : A-1440C |
14''- 40'' max load capacity:25kgs(55Ibs) |
|
|
Flat panel Tilt mount for screen size:14''-40''
> Fits most: 14''-40'' flat panel TV
> VESA compliance: 100*100mm,200*100mm,200*200mm
> Load capacity: 55Ibs(25kgs)
>Tilt angle:+15°/-5°
>Material: SPCC with coating finished
|
|
-
| Model : A-32070C |
40''- 70'' max load capacity: 34.1kgs(75IBS) |
|
|
Flat panel Tilt mount For screen sizes 40''-70''
> Fits most 40''-70'' flat panel TV
> VESA compliance: 100*100,200*100,200*200,200*300
300*300,200*400,300*400,400*400
> Load capacity: 75IBS(34.1kg)
> Tilt angle: +15°/-5°
> Material: SPCC with coating finished |
|
-
| Model : A-63102P |
Max hole distance:380mm/Max Load Capacity:30kg/Extension size:630-1000mm |
|
|
Projector ceiling mount
> Projector size: Universal
> Adjust angle: horizontal degree ±22.5°/ vertical degree ±15°
> Max hole distance: 380mm
> Max Load Capacity: 30kg
> Material: cold rolled steel
> Product Color: white
> Master Carton size: 53*49*33cm
> Extension size: 630-1000mm
> N.W/G.W: 32.5/33.8kgs
> Q'ty/Carton: 20PCS |
|
-
| Model : A-63101P |
Max hole distance:380mm/Max Load Capacity:30kg/Extension size:630-1000mm |
|
|
Projector ceiling mount
> Projector size: Universal
> Adjust angle: degree ±22.5°/vertical degree ±15°
> Max hole distanve: 380mm
> Max Load Capacity: 30kg
> Material: cold rolled steel
> Product Color: black
> Master Carton size: 53*49*33cm
> Extension size: 630-1000mm
> N.W/GM: 32.5/33.8kgs
> Q'ty/Carton: 20PCS |
|
-
| Model : A-43652P |
Max hole distance:380mm/Max load Capacity:30kg/Extension size:430-650mm |
|
|
Projector ceiling mount
> Projector size: Universal
> Adjust angle: horizontal degree ±22.5°/ vertical degree ±15°
> Max hole distance: 380mm
> Max Load Capacity: 30kg
> Material: cold rolled steel
> Product Color: white
> Master Carton size: 48*33*32cm
> Extension size: 430-650mm
> Gross/Net weight: 26/26.5kg
> Q'ty/Carton: 20PCS |
|
-
| Model : A-43651P |
Max hole distance:380mm/Max Load Capacity:30kg/Extension size:430-650mm |
|
|
Projector ceiling mount
> Productor size: Universal
> Ajust angle: horizontal degree ±22.5°/vertical degree ±15°
> Max hole distance: 380mm
> Max Load Capacity: 30kg
> Material: cold rolled steel
> Product Color: Black
> Master Carton size: 48*33*32cm
> Extension size: 430-650mm
> N.W/G.W: 26/26.5kg
> Q'ty/Carton: 20PCS |
|
-
| Model : A-RM18T |
17''- 32'' Load Capacity: 2-9kgs |
|
|
Gas Spring Monitor Arm
> Screen size: 17''-32''
> Max Vesa Size: 75*75mm
> Load Capacity: 2-9KG
> Arm Extension: 450mm
> Height adjusted: 110-430mm
> Rotation: 360°
> Color: Black
> Inner box size: 435*308*115mm
> Master Carton Size: 490*455*340mm
> Q'ty/Carton: 4pcs
> Product N.W/G.W: 3.9kg/4.9kg
> Carton N.W/G.W: 15.6kg/19.5kg |
|
-
| Model : A-RM17T |
17''- 32'' Load Capacity: 2-9kgs |
|
|
Gas Spring Monitor Arm
> Screen size: 17''-32''
> Max Vesa Size: 75*75mm / 100*100mm
> Load Capackity: 2-9KG
> Arm Extension: 450mm
> Height adjusted: 110-430mm
> Rotation: 360°
> Color: Black
> Inner box size: 423*175*115mm
> Master Carton Size: 435*365*365mm
> Q'ty / Caton: 6 pcs
> Product N.W/G.W: 2.32kg/2.92kg
> Carton N.W/G.W: 16kg/16.5kg |
|
-
| Model : A-RM16T |
17''- 32'' Load Capacity: 2-9kgs |
|
|
Desktop Monitor Mount
> Screen Size: 13'' -32''
> VESA Size: 75*75 / 100*100mm
> Max load Capacity: 9kg
> Fits table thickness: 10-88mm
> Height: 400mm
> Installation method: Table clamp; perforated
> Product NW: 2.6kg
> Carton GW: 17.3kg
> Inner box size: 432*205*76mm
> Master Carton Size: 540*445*240mm
> Q'ty / Carton: 6pcs
> Material: cold-rolled sheet + ABS Plastic |
|
-
| Model : A-RM43A |
26''-55'' max load capacity 20kgs(44Ibs) |
|
|
Full motion mount
> TV Size: 14''- 43''
> VESA Size: 200*200mm
> Max load Capacity: 18kg
> Tilt: ±15°
> Swivel: ±90°
> Thickness: 1.5mm
> Package: color box
> Master Carton Size: 470*250*250mm
> Q'ty/Carton: 10 PCS
> NW/GW: 12.8KG/13.3KG
> Distance to wall: 6.5-35cm
> HS code: 8529908100 |
|
-
| Model : A-RM2655 |
26''-55'' max load capacity 20kgs(44Ibs) |
|
|
Full motion mount
> TV Size: 26''-55''
> VESA Size: 400*400mm
> Max load Capacity: 20kg
> Tilt: ±13°
> Swivel: ±90°
> Thickness: 1.5mm
> Package: Color box
> Master Carton Size: 482*285*245mm
> Q'ty/Carton: 5PCS
> NW/GW: 10.4KG/10.9KG
> Distance to wall: 5.5-4.3cm
> HS code: 8529908100 |
|
-
| Model : A-1443A |
14''- 43'' max load capacity 25kgs(55Ibs) |
|
|
Tilt mount
> TV Size: 14''- 43''
> VESA Size: 200*200mm
> Max load Capacity: 25kg
> Tilt: ±15°
> Thickness: 1.1mm
> Package: color box
> Master Carton Size: 49*30*25.5cm
> Q'ty / Carton: 20PCS
> NW/GW: 15.4kg/16kg
> HS code: 8529908100 |
|
-
| Model : A-32801A |
32''- 80'' max load capacity 75kgs(165Ibs) |
|
|
Tilt mount
> TV Size: 32''- 80''
> VESA Size: 600*400mm
> Max load Capacity: 75kg
> Tilt: ±15°
> Thickness: 1.5mm
> Package: color box
> Master Carton Size: 67*35*18.5cm
> Q'ty/Carton: 8PCS
> NW/GW: 17.3 / 17.8KG
> HS code: 8529908100 |
|
-
| Model : A-2660A |
26''- 60'' max load capacity 30kgs(66Ibs) |
|
|
Tilt mount
> TV Size: 26''- 60''
> VESA Size: 400*400mm
> Mas load Capacity: 30kg
> Tilt: ±15°
> Thickness: 1.3mm
> Package: Color box
> Master Carton Size: 48*35.5*26cm
> Q'ty/ Carton: 20PCS
> NW/GW: 21.8KG/22.7KG
> HS code: 8529908100 |
|
-
| Model : A-RM3281 |
32''- 85'' max load capacity 45kgs(99Ibs) |
|
|
Full motion mount
> TV Size: 32''- 85''
> VESA Size: 600*400mm
> Max load Capacity: 45kg
> Tilt: ± 15°
> Swivel: ±90°
> Thickness: 1.5mm
> Package: color box
> Master Carton Size: 67*31*18cm
> Q'ty / Carton: 4PCS
> NW/GW: 19.5KG/20KG
> Distance to wall: 8-40cm
> HS code: 8529908100
|
|
-
| Model : A-55120A |
55''-120'' max load capacity 30kgs(66Ibs) |
|
|
Tilt mount
> Fits most 55''- 120'' flat panel TV
> VESA compiance: 200*200,200*400,300*300,
400*400,600*400,600*600,800*400,800*600mm
> Load capacity: 300ibs(150kg) |
|
|
| More in the development of similar products... |
|
|
|
